Compact, efficient, and globally compatible for modern road lighting.
The SL03 Series offers the perfect balance of cost efficiency and reliability.
Its tool-free design simplifies maintenance, while 3-in-1 power adjustment enhances flexibility for distributors and contractors.
The smooth, dust-free body and NEMA-compatible interface make SL03 a future-proof choice for global street lighting applications.
Watch how SL03 delivers professional stadium lighting performance with powerful output, precise optics and flexible control options.
Smooth Die-Cast Design - Prevents dust accumulation, corrosion-resistant.
Tool-Free Power Compartment - Safe and quick for maintenance crews.
3-in-1 Power Adjustment - Optimizes inventory and installation flexibility.
Thermal Isolation Structure - Protects driver and LED modules.
NEMA Sensor Compatible - Smart-ready for global controls.
Optical Types T2/T3/T4 - Covers single to multi-lane roadways.
Dual Mounting Options - Pole or wall mount, ±20° tilt adjustment.
High Efficiency up to 190 lm/W - Excellent brightness with energy savings.
Power Range 30-200W - Suitable for roads, parks, and community lighting.
Class I Electrical Safety - Reliable, compliant, and durable.
| Parameter | SL02-30W | SL02-60W | SL02-100W | ||||||
| Power (W) | 30W | 60W | 100W | ||||||
| Input Voltage | AC100-277V | ||||||||
| Luminous Efficacy | 140Lm/W | 140Lm/W | 140Lm/W | ||||||
| Luminous Flux | 4200 Lm | 8400 Lm | 14000 Lm | ||||||
| Beam Angle | T3 | ||||||||
| CCT | 3000K / 4000K / 5000K / 5700K / 6500K | ||||||||
| CRI | Ra70 | ||||||||
| SDCM | 6 | ||||||||
| Power Factor | ≥0.9 | ||||||||
| Parameter | SL02-30W | SL02-60W | SL02-100W | ||||||
| Structure Material | Die-casting Heat sink / ADC12 Aluminum Alloy | ||||||||
| Surface Finish | Powder Coating (Gray) | ||||||||
| Lens | Polycarbonate Optical Lens | ||||||||
| Parameter | SL02-30W | SL02-60W | SL02-100W | ||||||
| IP Rating | IP66 | ||||||||
| IK Rating | IK10 | ||||||||
| Protection Class | Class I | ||||||||
| Operating Temperature | -30°C to +50°C | ||||||||
| Lifetime | 50,000 hours | ||||||||
| Warranty | 5 years | ||||||||
| Surge Protection | Built-in 4kV, 6kV SPD ectra optional | ||||||||
| Parameter | SL02-30W | SL02-60W | SL02-100W | ||||
| Intelligent Control | 0-10V dimming, DALI | ||||||
| Certifications | CE, RoHS, ENEC | ||||||
Minimizes upward spill and light pollution.
Assists installers in quick and precise light alignment.
Provides extra protection for sports environments.
Discover how the SL03 Plus Series delivers exceptional performance, energy savings, and visual comfort for every arena.
For the fastest pricing, include model, quantity, application, and installation height.
